Kegellager Timken 47420DC, Buitendiameter: 120 mm | Binnendiameter: 69.85 mm | Breedte: 58.738 mm
Kegellager
Zie technische informatieReferenties
Timken:47420DC
Rubix:03322998
EAN:0053893303796
Technische samenvatting
| Binnendiameter | 69,85 mm |
|---|---|
| Buitendiameter | 120 mm |
| Breedte | 58,738 mm |
Productdetails : TIMKEN 47420 DC CUP
The configuration of the TDO provides a wide effective bearing spread, making it ideal for applications in which overturning moments are a significant load component. TDO bearings can be used in fixed positions or allowed to float in the housing bore.
Timken 47420DC cup voor kegelrollenlagers (TDO). Met gaten in de OD-center. OD 120 mm, breedte 71,435 mm en massa 3,058 kg.
Sterke punten
Double cup and two single cones, with or without a spacer. When spacers are used, bearing is furnished as a preset, matched assembly. Cup features groove and lubrication holes in the OD. Spacers available with or without lubricant grooves and holes.
Toepassingen
Heavy-duty gear drives; Various industrial configurations
Technische informatie
Attributen
| Verpakkingshoeveelheid | 1 |
|---|---|
| Logistieke afmetingen (D x B x H) | 58,674x119,888x119,888 mm |
| Logistiek gewicht | 1134 g |
| Afmeting verpakking (D x B x H) | 65,1256x136,6012x136,6012 mm |
| Binnendiameter | 69,85 mm |
| Buitendiameter | 120 mm |
| Breedte | 58,738 mm |
| Type lagerspeling | cn |
| Gewicht | 3,058 kg |
| Serie | 47400 |
| Totale breedte lager | 71,435 mm |
| Aangepaste tariefcode | 84822000 |
Laten zien UNSPSC / ECL@SS / HS-codes
€ 6.297,88 excl. BTW
/ stuk
€ 7.620,43 incl. BTW
- Levering doorgaans binnen 9 dagen
