Kegellager Timken HH228349/HH228310, Buitendiameter: 254 mm | Binnendiameter: 127 mm | Breedte: 77.788 mm
Kegellager
Zie technische informatieZie documentenReferenties
Timken:HH228349/HH228310
Rubix:03326523
EAN:0053893665078
Technische samenvatting
| Binnendiameter | 127 mm |
|---|---|
| Buitendiameter | 254 mm |
| Breedte | 77,788 mm |
Documenten
Productdetails : TIMKEN HH 228349/HH 228310 KEGELLAGER EENRIJIG
Single-row tapered roller bearings are the most basic and widely used, consisting of a cone assembly and a cup. Timken patented the first in 1898 and today offers the world's widest variety in inch and metric sizes. This is the most basic and most widely used type of tapered roller bearing. It consists of two main separable parts: the inner race assembly and the outer race. It is typically mounted in opposing pairs on a shaft.
This cup (outer ring) will need to be purchased with a matching cone (inner ring/cage/rollers).
This cup (outer ring) will need to be purchased with a matching cone (inner ring/cage/rollers).
Timken HH228349/HH228310 is een éénrijig kegellager (TS) voor betrouwbare radiale en gecombineerde belastingen. Leverbaar als taper roller bearing set met afmetingen 127×254×77,788 mm.
Sterke punten
Single cone. One-piece pressed steel cage retains rollers on the cone and spaces them evenly. Pin type cages also available.
Toepassingen
Vehicle front wheels; Differential and pinion configurations; Conveyor rolls; Machine tool spindles; Trailer wheels
Technische informatie
Attributen
| Verpakkingshoeveelheid | 1 |
|---|---|
| Logistieke afmetingen (D x B x H) | 61,913x254x254 mm |
| Logistiek gewicht | 6080 g |
| Afmeting verpakking (D x B x H) | 69,85x260,35x260,35 mm |
| Binnendiameter | 127 mm |
| Buitendiameter | 254 mm |
| Breedte | 77,788 mm |
| Type lagerspeling | cn |
| Gewicht | 17,9 kg |
| Serie | hh228300 |
| Koker | staal |
| Totale breedte lager | 77,788 mm |
| Statische basisbelasting, radiaal - C0r | 1240000 N |
| Dynamische basisbelasting, radiaal - Cr | 910000 N |
| Aangepaste tariefcode | 84822000 |
Laten zien UNSPSC / ECL@SS / HS-codes
€ 3.132,87 excl. BTW
/ stuk
€ 3.790,77 incl. BTW
- Levering doorgaans binnen 9 dagen
