Kegellager Timken HM746610, Buitendiameter: 355.6 mm | Binnendiameter: 228.6 mm | Breedte: 50.8 mm
Kegellager
Zie technische informatieReferenties
Timken:HM746610
Rubix:03326964
EAN:0053893679686
Technische samenvatting
| Binnendiameter | 228,6 mm |
|---|---|
| Buitendiameter | 355,6 mm |
| Breedte | 50,8 mm |
Productdetails : TIMKEN HM 746610 CUP
Single-row tapered roller bearings are the most basic and widely used, consisting of a cone assembly and a cup. Timken patented the first in 1898 and today offers the world's widest variety in inch and metric sizes. This is the most basic and most widely used type of tapered roller bearing. It consists of two main separable parts: the inner race assembly and the outer race. It is typically mounted in opposing pairs on a shaft.
This cup (outer ring) will need to be purchased with a matching cone (inner ring/cage/rollers).
This cup (outer ring) will need to be purchased with a matching cone (inner ring/cage/rollers).
Timken HM746610 kegelrollenlagerbeker (Type TS) voor gebruik in gepaarde kegelrollenlageropstellingen. Robuust ontwerp voor hoge radiale/axiale belasting.
Sterke punten
Single cone. One-piece pressed steel cage retains rollers on the cone and spaces them evenly. Pin type cages also available.
Toepassingen
Vehicle front wheels; Differential and pinion configurations; Conveyor rolls; Machine tool spindles; Trailer wheels
Technische informatie
Attributen
| Verpakkingshoeveelheid | 1 |
|---|---|
| Logistieke afmetingen (D x B x H) | 50,8x355,6x355,6 mm |
| Logistiek gewicht | 6963 g |
| Afmeting verpakking (D x B x H) | 374,65x81,026x374,65 mm |
| Binnendiameter | 228,6 mm |
| Buitendiameter | 355,6 mm |
| Breedte | 50,8 mm |
| Type lagerspeling | cn |
| Gewicht | 26,3 kg |
| Serie | hm746600 |
| Koker | staal |
| Totale breedte lager | 69,85 mm |
| Norm | TYPE TS |
| Statische basisbelasting, radiaal - C0r | 1690000 N |
| Dynamische basisbelasting, radiaal - Cr | 951000 N |
| Aangepaste tariefcode | 84822000 |
Laten zien UNSPSC / ECL@SS / HS-codes
€ 3.109,03 excl. BTW
/ stuk
€ 3.761,93 incl. BTW
- Levering doorgaans binnen 9 dagen
