Kegellager Timken 614X, Buitendiameter: 115.001 mm | Binnendiameter: 88.9 mm | Breedte: 31.496 mm
Kegellager
Zie technische informatieReferenties
Timken:614X
Rubix:03324000
EAN:0053893070278
Technische samenvatting
| Binnendiameter | 88,9 mm |
|---|---|
| Buitendiameter | 115,001 mm |
| Breedte | 31,496 mm |
Productdetails : TIMKEN 614 X CUP
Single-row tapered roller bearings are the most basic and widely used, consisting of a cone assembly and a cup. Timken patented the first in 1898 and today offers the world's widest variety in inch and metric sizes. This is the most basic and most widely used type of tapered roller bearing. It consists of two main separable parts: the inner race assembly and the outer race. It is typically mounted in opposing pairs on a shaft.
This cup (outer ring) will need to be purchased with a matching cone (inner ring/cage/rollers).
This cup (outer ring) will need to be purchased with a matching cone (inner ring/cage/rollers).
Timken 614X is een single cup (buitenring) van een taps toelopend rollager. Het wordt gebruikt met de bijpassende conus en heeft D=115,001 mm en C=31,496 mm.
Sterke punten
Single cone. One-piece pressed steel cage retains rollers on the cone and spaces them evenly. Pin type cages also available.
Toepassingen
Vehicle front wheels; Differential and pinion configurations; Conveyor rolls; Machine tool spindles; Trailer wheels
Technische informatie
Attributen
| Verpakkingshoeveelheid | 1 |
|---|---|
| Logistieke afmetingen (D x B x H) | 31,496x115,001x115,001 mm |
| Logistiek gewicht | 550 g |
| Afmeting verpakking (D x B x H) | 34,544x133,858x133,858 mm |
| Binnendiameter | 88,9 mm |
| Buitendiameter | 115,001 mm |
| Breedte | 31,496 mm |
| Type lagerspeling | cn |
| Gewicht | 1,8 kg |
| Serie | ts |
| Materiaal | lagelegering koolstof-chroom lagerstaal (52100 en andere), volgens astm a295 |
| Koker | staal |
| Norm | ASTM A295 |
| Statische basisbelasting, radiaal - C0r | 441000 N |
| Dynamische basisbelasting, radiaal - Cr | 327000 N |
Laten zien UNSPSC / ECL@SS / HS-codes
€ 781,63 excl. BTW
/ stuk
€ 945,77 incl. BTW
- Levering doorgaans binnen 9 dagen
