Kegellager Timken L45410-20395, Buitendiameter: 50.292 mm | Binnendiameter: 28.999 mm | Breedte: 10.668 mm
Kegellager
Zie technische informatieReferenties
Timken:L45410-20395
Rubix:03327885
EAN:0053893153971
Technische samenvatting
| Binnendiameter | 28,999 mm |
|---|---|
| Buitendiameter | 50,292 mm |
| Breedte | 10,668 mm |
Productdetails : TIMKEN L 45410-20395 CUP
Single-row tapered roller bearings are the most basic and widely used, consisting of a cone assembly and a cup. Timken patented the first in 1898 and today offers the world's widest variety in inch and metric sizes. This is the most basic and most widely used type of tapered roller bearing. It consists of two main separable parts: the inner race assembly and the outer race. It is typically mounted in opposing pairs on a shaft.
This cup (outer ring) will need to be purchased with a matching cone (inner ring/cage/rollers).
This cup (outer ring) will need to be purchased with a matching cone (inner ring/cage/rollers).
Timken kegelrollenlager-cup L45410-20395 is een enkel lagerkapsel voor montage in paren met een conus. C0r 36200 N.
Sterke punten
Single cone. One-piece pressed steel cage retains rollers on the cone and spaces them evenly. Pin type cages also available.
Toepassingen
Vehicle front wheels; Differential and pinion configurations; Conveyor rolls; Machine tool spindles; Trailer wheels
Technische informatie
Attributen
| Verpakkingshoeveelheid | 1 |
|---|---|
| Logistieke afmetingen (D x B x H) | 10,668x50,292x50,292 mm |
| Logistiek gewicht | 36 g |
| Afmeting verpakking (D x B x H) | 25,146x59,182x59,182 mm |
| Binnendiameter | 28,999 mm |
| Buitendiameter | 50,292 mm |
| Breedte | 10,668 mm |
| Type lagerspeling | cn |
| Gewicht | 0,1 kg |
| Serie | l45400 |
| Koker | staal |
| Totale breedte lager | 14,224 mm |
| Statische basisbelasting, radiaal - C0r | 36200 N |
| Dynamische basisbelasting, radiaal - Cr | 35500 N |
Laten zien UNSPSC / ECL@SS / HS-codes
€ 9,91 excl. BTW
/ stuk
€ 11,99 incl. BTW
- Levering doorgaans binnen 9 dagen
